FRAME:Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capac
REAR SHOCK:Fox Float-X LV Factory Kashima, 205x65mm. Settings: compression 2 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
FORK:Fox 38 29 Float GRIP2 Factory Kashima, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high and low-speed compression, high and low-speed rebound, air preload
HEADSET:Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45°
STEM:Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore
HANDLEBAR:Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9° backsweep, 5° upsweep, 31.8mm barbore
GRIPS:Onoff Desert, 1lock-on, 135mm
SEATPOST:Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M/L size: 418.3x150mm, XL size: 475.1x175mm
SADDLE:FIZIK Terra Aidon X5 145mm
FRONT BRAKE:Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
REAR BRAKE:Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
FRONT HUB:Mavic, Boost 15x110mm, IS 6 bolts
REAR HUB:Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
FRONT TYRE:Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
REAR TYRE:Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
CRANKSET:Race Face Aeffect ebike, 165mm
CHAINRINGS:Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104
BCDCHAIN:Sram NX Eagle, 12s, Powerlock
REAR DERRAILLEUR:Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
SHIFT LEVERS:Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click
CASSETTE:Sram XG-1230, 11-50T, 12s
MOTOR:Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3
BATTERY:Bosch Powertube 750Wh
DISPLAY:New Bosch Kiox
