Frame
F-Play 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
Rear Shock
X-Fusion 02PRO R, 210×47.5mm. Settings: low-speed rebound, air preload. 45×8mm top and bottom bushings
Fork
X-Fusion Velvet RL 26, 100mm, Air Sprung, Tapered Steerer Tube, 9×100mm axle, 32mm Aluminium stanction, 41mm Offset. Settings: Lockout, Rebound, Air Pressure
Display
Mahle Ebikemotion
Motor
Mahle Ebikemotion X-35
Battery
Mahle Ebikemotion 250Wh, Intergrated
Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2×7×45ºx45º, bottom 51.9×40×8×45ºx45º
Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips
Onoff Twin, 1lock-on
Seatpost
MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 350mm
Saddle
SDG Fly JR
Front Brake
SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear Brake
SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rims
MDK-XP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Front Hub
Formula DC20LW, 9×100mm, cup & cone ball bearings, IS 6 bolts
Rear Hub
Mahle-Ebikemotion X-35
Front Tyre
Kenda Booster 24×2.4 single compound 30TPI, wire bead
Rear Tyre
Kenda Booster 24×2.4 single compound 30TPI, wire bead
Crankset
Sram SX Eagle, DUB Axle, Direct Mount Chainring, 155mm
Chainring
30 Tooth, X-Sync
Bottom Bracket
Sram DUB BSA, 73mm
Chain
Sram SX Eagle, 12-Speed, Powerlock
Rear Derailleur
Sram SX Eagle, Roller Bearing Clutch Type 3, Cage Lock, 1×12, X-Actuation 1:1
Shifter
Sram Trigger SX Eagle, 12-Speed, X-Actuation 1:1
Cassette
Sram XG-1230, 11-50Z, 12-Speed
Derailleur Hanger
Mondraker M073
