Frame
SCREE 6061 Alloy Stealth Evo, Updated Zero Suspension System, 130mm Travel, Forward Geometry, Internal Removable Battery, Boost 12x148mm Rear Axle, UDH, Tapered Head Tube, One-piece Monoblock Upper Link, HHG Internal Cable Routing, MAX Capacity Sealed Bearings, Oversize 15mm Axles, Exclusive Plastic Motor Covers
Shock
Fox Float Rhythm EVOL, 165x45mm, Settings: 2-position Compression (Open/Firm), Rebound, Air Preload. Trunnion Top Mount, 30x8mm Bottom Bushings
Fork
Fox 36 29 Float Rhythm, 150mm Travel, Tapered Steerer Tube, Boost 15x110mm Kabolt Axle, 44mm Offset. Settings: GRIP Sweep-Adjust
Motor
Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)
Battery
Bosch Powertube 800Wh
Display
Kiox 400C, Bosch Mini Remote
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" Head Tube, Internal Cable Routing, Sealing Plugs without Blocklock
Chainring
SRAM Eagle T-Type, 34T, Direct Mount, Steel, CL555
Crank
E.13 Helix Core E*Spec Plus, 160mm
Shifters
SRAM Trigger 70, T-Type Actuation, 12 Speed
Cassette
SRAM XS-1270, 10-52T, 12 Speed
Rear derailleur
SRAM 70 Eagle, T-Type, 12 Speed
Chain
SRAM 70 T-Type, 12 speed, Powerlock
Brakes
SRAM DB6 Hydraulic Disc, 4-piston Caliper, Rotors: Centerline 200mm, IS 6 Bolts, One-piece
Handlebar
OnOff S6 1.0 7050 Alloy, Rise: 25mm, Width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. (L and XL size: 38mm rise)
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Stem
OnOff S6, 30mm, 0º, 6061 Forged Alloy + CNC, 31.8mm barbore
Seatpost
X-Fusion Manic Dropper, 31.6mm, 1X Remote Lever, S Size: 361x125mm, M Size: 425x150mm, M/L Size: 469x170mm, L Size: 521x190mm, XL Size: 531x200
Saddle
Ergon SMC10 Gel
Front Hub
e*thirteen Boost 15x110mm, Triple-Sealed, Fully Machined Aluminium, IS 6 Bolts
Rear Hub
e*thirteen Boost 12x148mm, Triple-Sealed, Fully Machined Aluminium w/6-Degree Engagement, IS 6 Bolts, HG Freehub
Rims
e*thirteen Grappler Core, IW30 Hookless, 6066 Welded Aluminium, 30mm Internal Width, Tubeless Ready, 28 Spokes
Spokes
e*thirteen Custom Hive Triple-Butted Black Steel, Alloy Nipples, Nipple Washers
Front Tyre
Maxxis Dissector, 29x2.6", Tubeless Ready, 3C MaxxTerra Compound, EXO+ Protection, 60TPI, Folding Bead
Rear Tyre
Maxxis Dissector, 29x2.6", Tubeless Ready, 3C MaxxTerra Compound, EXO+ Protection, 60TPI, Folding Bead
