Frame

Frame:
Xroad Open frame constructed from 6061 T4-T6 aluminium alloy with hydroformed tubing and extruded triple-cavity tubes for enhanced stiffness. The frame includes integrated Bosch PowerTube battery integration and internal cable routing for a clean, modern finish.

Suspension

Fork:
SR Suntour XCM32-ATB suspension fork with preload adjustment and lockout, providing 100mm of travel for improved comfort and control on rough surfaces.

Motor System

Motor:
Bosch Performance Line (BDU34) Smart System, delivering 75Nm of torque for powerful and responsive assistance.

Battery:
Bosch PowerTube 600Wh integrated battery with Smart System compatibility.

Maximum Range:
Up to 144 km, depending on riding conditions and assistance mode.

Charger:
Bosch 2A charger

Display / Remote:
Bosch Purion 200 control unit with Smart System integration.

Drivetrain

Cassette: Shimano CUES CS-LG300, 9-speed, 11–36T

Chain: Shimano CN-LG500, 120 links

Shifter: Shimano CUES SL-U4000-9R, 9-speed

Rear Derailleur: Shimano CUES RD-U3020, 9-speed

Crankset: Stronglight aluminium crank arms, 170mm

Chainring: Narrow-Wide 40T

Brakes

Front Brake: Shimano MT200 hydraulic disc brake
Rear Brake: Shimano MT200 hydraulic disc brake

Rotors:

• Front: 180mm

• Rear: 180mm

Wheels & Tyres

Front Hub: Shimano, 32H, 9×100mm, quick release
Rear Hub: Shimano, 32H, 9×100mm, quick release

Rims:
Alloy rims, 27.5", 32 holes, 23mm internal width

Tyres:
Schwalbe Smart Sam, 27.5 × 2.25

Cockpit & Comfort

Saddle: Selle Royal Essenza+ Moderate

Seatpost: Suspension seatpost, alloy, 31.6mm, 350mm, 40mm travel

Seat Clamp: Moustache alloy, 34.9mm

Handlebar: Moustache ergonomic alloy handlebar, 660mm width, 30° backsweep

Stem: Moustache adjustable alloy stem, 65mm

Headset: Acros AZF-699, sealed bearings with internal routing and BlockLock

Grips: SB3 ergonomic grips

Equipment

Front Light: AXA NXT, 30 lux, powered by main battery
Rear Light: Spanninga Presto2Guard, powered by main battery

Bell: Spanninga Minibell Black

Lock: ABUS 4650SL frame lock (same key for frame lock and battery)

Kickstand: Adjustable Moustache kickstand

Mudguards: Moustache alloy, double-wall design with alloy stays

Rear Carrier:
Moustache alloy carrier with removable QL3 lateral fixation and MIK HD platform (compatible with Moustache Protect option)

Pedals: Alloy platform pedals with reflectors

Specifications

Size: S
Weight: 26.6 kg
Maximum System Weight (GVWR): 135 kg

Warranty

• 5 years: Frame and fork (Moustache Bikes)

• 2 years: Motor and battery
