FRAME
FOXY 29 6061 ALLOY STEALTH EVO, HYDROFORMED TUBING, ZERO SUSPENSION SYSTEM, 150MM TRAVEL, FORWARD GEOMETRY, ONE PIECE MONOBLOCK UPPER LINK, BOOST 12X148MM REAR AXLE, TAPERED HEAD TUBE, 73MM BSA BOTTOM BRACKET, DEDICATED 1X DRIVETRAIN DESIGN, TELESCOPIC SEATPOST INTERNAL ROUTING, MAX CAPACITY SEALED BEARINGS, ISCG 05
SIZES
S: 380MM / M: 420MM / L: 470MM / XL: 510MM
REAR SHOCK
FOX FLOAT DPX2 LV EVOL PERFORMANCE, 205X62.5MM. SETTINGS: COMPRESSION 3 POSITIONS LEVER, LOWSPEED REBOUND, AIR PRELOAD. TRUNNION TOP MOUNT, 22.2X10MM BOTTOM BUSHINGS
SHOCK SETTINGS
LIGHT COMPRESSION, EXTRALIGHT REBOUND, AIR VOLUME SPACER 0.6
FORK
FOX 36 29 FLOAT FIT GRIP EVOL PERFORMANCE, 160MM, TAPERED STEERER TUBE, BOOST 15X110MM AXLE, OFFSET 44MM. SETTINGS: 3 POSITIONS WITH MICRO ADJUST COMPRESSION, LOW-SPEED REBOUND, AIR PRELOAD
HEADSET
ONOFF SATURN TAPERED FOR 1-1/8" TO 1-1/2" HEAD TUBE, ACB SEALED BEARINGS, TOP 41X30.2X7X45"X45", BOTTOM 51.9X40X8X45"X45"
STEM
ONOFF SULFUR FG 30MM 0", 6061 FORGED ALLOY, 31.8MM BARBORE
HANDLEBAR
ONOFF SULFUR 1.0 DOUBLE BUTTED 6061 ALLOY, RISE: 20MM, WIDTH: 780MM, 9° BACKSWEEP, 5° UPSWEEP, 31.8MM BARBORE
GRIPS
ONOFF TWIN, 1LOCK-ON, 135MM
SEATPOST
ONOFF PIJA DROPPER INTERNAL, DIAMETER 31.6MM, S SIZE: 337X100MM, M SIZE 387X125MM, L SIZE: 425X150MM, XL SIZE: 465X170MM
SADDLE
SDG BEL-AIR 3.0, LPU FOAM, STEEL RAILS
FRONT BRAKE
SRAM G2 RS, 4-PISTON CALIPER, CENTERLINE 200MM IS 6 BOLTS ONE-PIECE ROTOR, STEEL-BACKED ORGANIC PADS
REAR BRAKE
SRAM G2 RS, 4-PISTON CALIPER, CENTERLINE 180MM IS 6 BOLTS ONE-PIECE ROTOR, STEEL-BACKED ORGANIC PADS
BRAKE LEVER
SRAM G2 RS, SWINGLINK, TOOL-FREE REACH ADJUST
RIMS
DT SWISS E1900 SPLINE 29, 30MM INTERNAL WIDTH, SLEEVED ALUMINUM, TUBELESS READY, 28 SPOKES
SPOKES
DT CHAMPION, STRAIGHTPULL
FRONT HUB
DT 370, BOOST 15X110MM, IS 6 BOLTS
REAR HUB
DT 370, BOOST 12X148MM, 3 PAWL SYSTEM, IS 6 BOLTS, MS FREEHUB
FRONT TYRE
MAXXIS MINION DHF 29X2.5 WT, TUBELESS READY, 3C MAXX TERRA COMPOUND, EXO+ PROTECTION, 120TPI, FOLDING BEAD
REAR TYRE
MAXXIS AGGRESSOR 29X2.3, TUBELESS READY, DUAL COMPOUND, EXO PROTECTION, 60TPI, FOLDING BEAD
CRANKSET
SHIMANO XT M-8120 BOOST, HOLLOWTECH II, Q-FACTOR 178MM, S/M SIZE: 170MM, L/XL SIZE: 175MM
CHAINRING
32T, CNC-MACHINED ALLOY
BOTTOM BRACKET
SHIMANO DEORE BB52 BSA, 68/73MM
PEDALS
---
CHAIN
SHIMANO DEORE M6100, 12S, QUICK-LINK
FRONT DERRAILLEUR
---
REAR DERRAILLEUR
SHIMANO XT M8100, SGS, SHADOW+, 12S
SHIFT LEVERS
SHIMANO DEORE M6100, RAPID FIRE PLUS, 12S
CASSETTE
SHIMANO SLX M7100, 10-51T HYPERGLIDE+, 12S
DERAILLEUR HANGER
MONDRAKER M068
