The experts at Colnago have done the seemingly impossible by taking the C59 and making it even better. Introducing the C60, at home on both the racing circuit as it is on the sportive scene.
The experts at Colnago have done the seemingly impossible by taking the C59 and making it even better. Introducing the C60, at home on both the racing circuit as it is on the sportive scene.
Colnago

Colnago C60 Dual Use Classic Maserati Blue Frameset

£3,499.95
Click & Collect for Free
Earn
 in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on the Undetermined

Colnago C60 Dual Use Classic Maserati Blue Frameset Information

Season : 2015

Brand : Colnago

Code : C60-OFMA

Frame & Fork set only.



Compatible with Di2/EPS and mechanical systems. Not disc brake compatible.



The ultimate goal is to improve the bicycle: to make it more efficient, with less rider fatigue and no sacrifice in strength or reliability. The design must be striking. From a marketing standpoint, the frame's characteristics and technical advantages must stand out and not be completely hidden inside the frame. Star-shaped tubes are a proven design element and have become a signature design element for Colnago frames. It is from this proven design, with the goal of increased frame efficiency without significant sacrifice in comfort or strength, with which the Colnago C60 was born.



In the C60 various cross sections of tubes have increased volume, thinner walls and drastic tube profiles. No attention to detail was spared. The rear dropouts have been completely redesigned for reduced weight and increased lateral stiffness. Even the water bottle mounts were redesigned to reduce weight while maximising strength.



HEADTUBE

The most striking difference between the C59 and C60 is the new tube shapes and its matching shaped lugs.



DOWNTUBE

The second major difference between the C59 and the C60 is the new oversized downtube.



SEATTUBE

In favour of a round tube shape, the seat tube becomes strongly asymmetric as it reaches and enters the bottom bracket lug.



BOTTOM BRACKET LUG

The heart of the new C60 is the bottom bracket. The dimensions of this masterpiece, especially when compared to that of the C59, have been created to ensure the ultimate in lateral stiffness.



ONE PIECE DROPOUTS

Another new feature introduced with C60 are the forged, CNC-machined one-piece dropouts. With the C60, Colnago has worked hard to make the connection between the frame and the rear wheel a true masterpiece.



PAINTING

Colnago C60 frames painting, hand made in Italy one by one, every frame is unique!



UCI APPROVED

This frame is approved by the International Cycling Union and therefore used in all races recognised by the UCI.

Sizing Information

Size - Size
Pccs  - Seat tube length (centre to centre)
Ps - Seat tube length (centre to top)
P - Effective seat tube length
Os - Top tube length
O - Top tube length (horizontal)
Sc° - Seat angle
Scs - Seat cluster offset
C - Chainstay length
A - Front centre
Hs - Height head tube





SLOPING

Size

Ps

Os

Pccs

Scs

Sc°

A

C

Hs

Ss°

Bb drop



P

O



Stack

Reach

42s

420

495

395

99

75.49°

580

397

122

70,8°

65



510

510



516

376

45s

450

505

425

108

75.14°

582

399

125

71,15°

68



515

519



524

380

48s

480

520

455

121

74.58°

584

402

127

71,52°

69



520

530



528

383

50s

500

528

475

131

74°

589

405

145

71,62°

70



540

540



547

383

52s

520

538

495

141

73.57°

593

407

163

71,92°

70



560

550



565

384

54s

540

550

515

151

72.83°

596

409

179

72,49°

70



580

565



582

385

56s

560

568

525

156

72.75°

606

412

187

72,88°

70



600

580



591

396

58s

580

578

540

160

72.75°

614

413

204

73,12°

70



620

590



608

401

60s

600

585

554

164

72.75°

619

414

225

73.3°

70



640

598



628

403
