FRAME
Lumen eRIDE Carbon HMX, Integrated Suspension Technology, Flex Pivot, Adjustable head angle, Syncros Cable Integration System, TQ HPR50, UDH Interface, 12x148mm with 55mm Chainline
TRAVEL
Front: 130mm / Rear: 130mm
FORK
FOX 34 Float Performance Elite Air, FIT4, 3-Modes with low Speed adjust, Kabolt 15x110mm axle, 44mm offset, tapered steerer, Reb. Adjust, Lockout, 130mm travel
REAR SHOCK
FOX NUDE 6T EVOL Trunnion, SCOTT custom w. travel / geo adjust, 3 modes: Lockout-Traction Control-Descend, Custom large Air volume, Reb. Adjust, Travel 130-90-Lockout, T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
DRIVE UNIT
TQ HPR50 Mid Motor drive, 50Nm max Torque
BATTERY
TQ Internal 360Wh
DISPLAY
TQ HPR, Bluetooth, ANT+, Dedicated Smartphone app
CHARGER
TQ 100-240V-4A
REAR DERAILLEUR
SRAM GX Eagle AXS Transmission, 12 Speed, Wireless Electronic Shift System
SHIFTERS
SRAM GX Eagle AXS Rocker Controller
CRANKSET
FSA Carbon crankset, 175mm, 34T
CHAINGUIDE
e*thirteen, e*spec Slider
CHAINRING
Scott custom spider, SRAM Eagle Transmission, 34T
CHAIN
SRAM CN NX Eagle Transmission
CASSETTE
SRAM GX Eagle XG 1275 Transmission, 10-52 T
BRAKES
SRAM Level Silver Stealth 4-Piston Disc
ROTORS
SRAM HS2 CL, F&R 180mm
HANDLEBAR
Syncros Fraser iC SL DC Carbon, 0° rise, back sweep 8°, mini Rise, 760mm, Syncros Performance XC lock-on grips
SEATPOST
FOX Transfer Dropper Post, 31.6mm, S size 125mm, M size 140mm, L size 150mm, XL size 175mm
SEAT
Syncros Tofino 1.5 Regular, Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton 1.5-30 CL, F: 15x110mm, R: 12x148mm, 30mm. Tubeless ready rim. 28H, XD Driver, Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
FRONT TYRE
Schwalbe Wicked Will, 29x2.4", EVO, Super Race, TLE, 67EPI, Addix Speed Soft
REAR TYRE
Schwalbe Wicked Will, 29x2.4", EVO, Super Race, TLE, 67EPI, Addix Speed Grip
EXTRAS
SRAM AXS Powerpack, Syncros Fork Fender
ACCESSORIES
Syncros Eco Sealant, Transport Axle
APPROX WEIGHTS IN KG
16.6 (With Tubes)
APPROX WEIGHTS IN LBS
36.6 (With Tubes)
MAX. SYSTEM WEIGHT
128kg. The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
