Frame
Carbon Main Frame, Alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready, Kickstand mount
Travel
Front: 150mm, Rear: 150mm
Fork
FOX 36 Rhythm Air, eMTB+, Grip, Compression & Rebound Adjust, QR Axle 15x110mm axle, 44mm offset, tapered steerer, 150mm travel
Rear Shock
FOX Float EVOL Trunnion, 3 modes: Lockout-Trail-Descend, DPS, Rebound Adjust, 185x55mm
Remote System
SCOTT TracLoc 2 Technology, Suspension & Dropper Remote, 3 modes
Drive Unit
Bosch Performance Line CX (BDU384Y)
Battery
PowerTube 800Wh
Display
Bosch System Controller, Mini Remote and Kiox 300
Charger
4A Charger
Rear Derailleur
SRAM S1000 Eagle AXS T-type, 12 Speed, Wireless Electronic Shift System
Shifters
SRAM AXS Rocker Pod Controller
Crankset
FSA, Alloy
Chainguide
e*thirteen, e*spec Slider
Chainring
SRAM Eagle T-type 34T, SCOTT custom spider
Chain
SRAM CN GX Eagle T-type
Cassette
SRAM Eagle XS 1270 T-type, 10-52t
Brakes
Shimano Deore M6120 4-Piston Disc
Rotor
Front: SM-RT64 CL 220mm, Rear: SM-RT64 CL 203mm
Handlebar
Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm, Syncros Performance XC lock-on grips
Stem
Syncros AM 2.0, Syncros Cable Integration System, 4° rise, 6061 Alloy, 31.8mm, 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.5, 31.6mm, S size 125mm, M size 150mm, L size 170mm, XL size 200mm
Seat
Syncros Tofino-E 2.0 Regular
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Front Hub
Formula CL-811, 15x110mm
Rear Hub
Formula ECT-148S, Boost 148x12mm
Rims
Syncros MD30, 32H, 30mm, Pin Joint, Tubeless ready
Front Tyre
Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO, TR Tubeless ready, 3C Maxx Terra
Rear Tyre
Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO, TR Tubeless ready, 3C Maxx Terra
Lights
Syncros integrated rear fender light, Front Light Cable pre-installed
Approx weight in KG
24.4
Approx weight in LBS
53.79
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage
